JY-XHDHCLJ-F300-XX
Technical Data
| Product Specification | Remark | |||
| Description | LED Roadway Signal Light / Toll Station / Tunnel Application (red cross and green arrow) (square shape) | LED Dot Matrix & (optional for include top flash lights or not-include) | ||
| Model Number | JY-XHDHCLJ-F300-XX | |||
| Product Dimensions | 300*300*140 mm (230*230 emitting area size) | |||
| Voltage | AC85-265V 50/60Hz | |||
| Color | Red / Green | |||
| Red | Light intensity | ≥400 cd | ||
| Wavelength | 620±5nm | |||
| Power Consumption | ≦10W | |||
| Beam angle: | 30 degree | |||
| Yellow | Light intensity | ≥400 cd | ||
| Wavelength | 590±5nm | |||
| Power Consumption | ≦9W | |||
| Beam angle: | 30 degree | |||
| Green | Light intensity | ≥600 cd | ||
| Wavelength | 505±5nm | |||
| Power consumption | ≦10W | |||
| Beam angle | 30 degree | |||
| Visible Distance | >500 m | |||
| Outer Case Material | Metal plate | |||
| LED Average Life Time | ≥100000 H | |||
| Working Temperature | -20-80 ℃ | |||
| Ingress Protection | IP54 | |||
